The YBF-12 Step-up Box Substation is a fully integrated, factory-assembled solution designed for solar photovoltaic power plants. It combines a high-efficiency oil-immersed transformer, HV and LV switchgear, and auxiliary systems in a single weatherproof enclosure. Rated primary voltage up to 12kV and secondary voltage 0.4kV, it steps up generator output for grid connection. The substation features a robust steel housing with IP54 protection, corrosion-resistant coating, and natural cooling. Integrated protection relays, surge arresters, and a smart control panel ensure reliable operation and remote monitoring. Typical capacity ranges from 200kVA to 2000kVA, catering to medium and large solar installations. Easy to transport, install, and maintain, the YBF-12 is ideal for utility-scale solar farms, commercial rooftops, and distributed generation projects.
Technical Specifications
| Rated High Voltage (HV) | 12 kV |
| Rated Low Voltage (LV) | 0.4 kV |
| Rated Capacity | 630 kVA (customizable) |
| Cooling Type | ONAN (Oil Natural Air Natural) |
| Enclosure Material | Steel with anti-corrosion coating |
| Protection Level | IP54 |
| Standards | IEC 60076, GB/T 17467 |
| Frequency | 50/60 Hz |
| Winding Material | Copper |
| Application | Solar photovoltaic power station |
Why Choose This Product
- Compact integrated design with pre-wired transformer and switchgear, reducing installation time and space
- High efficiency step-up from 0.4kV to 10kV/12kV, optimized for solar farm applications
- Rugged outdoor enclosure with IP54 protection, corrosion-resistant and weatherproof
- Built-in protection relays and smart monitoring for safe and reliable operation
Contact Us
For wholesale pricing, technical specifications, or customized solutions, please contact us via WhatsApp or email. We offer factory-direct prices with professional support.
